Description
TECHNICAL SPECS. & STANDARD ACCESSORIES
Optional Equipments
- High efficiency on heavy plate bending operation
- Reduced overall dimensions and easiness of transportation on medium and big machines
- Having the two bottom rolls horizontally moving, means also a lower working height which requires a smaller foundation pit and less anchoring load (in the smallest models you don't need foundation)
- On smaller no need to place by digging.
- During operation (pre-bending and bending phases), the plate always keeps its horizontal position. So material move more easily
- The solid construction and the particular geometry of the 3R UHS enable to be used as a press brake bending machine
- The 3R UHS machine can fulfill the best pre-bending on every required diameter.
- The posibility to reduce centre-distance between lower rolls realizes a better pre-bending during bending of tubes with small diameter and thickness
- Another important future of the 3R UHS machine is the operating system of the top forming roll. In fact, the top forming roll can be used as a traditional press brake allowing perfect re-rolling and calibration operations of the produced tubes
- In the same way it is also possible to obtain cones with heavy thickness by bending in several strokes the plate
- With some 3 and 4 rolls pyramidal machines it is necessary to tilt the top roll to allow the produced tube removal. On the 3R UHS machine this is not necessary and therefore it is much more easier to remove the finished tube
- Large working stroke allows to get best bending result
- Can bend more thicker plates compare to equivalent 3 or 4 roll machines
- Induction hardened forged or rolled SAE 1050 (CK 45) Steel Rolls
- Double Speed Working system
- Conical Bending device
- Electronic balancing system
Optional Equipments
- • NC Control system
- Overhead Crane for large diameters
- Hydraulic lateral side support for large diameters
